Wireless Extender

  • CWE-3103
  • CWE-3103
  • CWE-3103
  • CWE-3103
  • CWE-3103
CWE-3103CWE-3103CWE-3103CWE-3103CWE-3103

CWE-3103

  • 2* 2dBi External Antennas
  • 1* 10/100Mbps WAN/ LAN auto port
  • Complies with IEEE802.11n/g/b
  • Provide work mode: Repeater
  • Product description: This WiFi extender booster, widely compatible with IEEE 802.11n/g/b standards, shows high-speed wireless transmission up to 300Mbps.
  • INQUIRY   EMAIL
This WiFi extender booster, widely compatible with IEEE 802.11n/g/b standards, shows high-speed wireless transmission up to 300Mbps. Also with two external antennas,the network have stronger anti-interference and stronger wireless signal. Allowing you to enjoy any internet activities smoothly.

Feature:
1. 300Mbps 2.4G WiFi Range Extender;
2. 2* 2dBi External Antennas;
3. Provides 1* 10/100Mbps WAN/ LAN auto port;
4. Complies with IEEE802.11n/g/b standards;
5.  Wireless Signal Rates:
     2.4G:  IEEE802.11n: up to 300Mbps (dynamic);
     2.4G:  IEEE802.11g: up to 54Mbps (dynamic);
     2.4G:  IEEE802.11b: up to 11Mbps (dynamic);
6. Easy setup assistant provides quick & hassle free installation;
7. Provide work mode: Repeater;
8. Supports remote/local web management and web upgrade;
9. Suitable for Home, Office, Hotel, Coffee shop and Library etc.

Specification:
Chipset-------------------------------------------RTL8196E
Interface------------------------------------------1* 10/100Mbps WAN/ LAN auto port;
Wireless speed-----------------------------------802.11n: up to 300Mbps
Frequency range---------------------------------2.4-2.484GHz
Wireless transmit power-------------------------20dBm(max EIRP)
Antenna-----------------------------------------2* 2dBi External Antennas
Work mode-------------------------------------Repeater
Wireless security--------------------------------64/128 Bits WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Power supply-----------------------------------AC100-240V input
Operating Temperature-------------------------20℃ to 70℃
Storage Temperature---------------------------40℃ to 90℃
Operating Humidity-----------------------------10% to 95% (non-condensing)
Storage  Humidity-------------------------------5% to 95% (non-condensing)
Support operating system----------------------Windows XP/ Vista/ Linnux/ Win 7/ Win 8 / Win8.1 / Win10 / Mac OS
Dimensions (H*W*D)----------------------------82*55*72mm

Packing list:
1* 300Mbps 2.4G WiFi Range Extender
1* Quick Installation Guide

Notes:
1. WiFi Range Extender(Repeater):  Extend WiFi coverage of an existing wireless network;
2. Wireless Access Point(AP):  Covert a wired network to a wireless network;
3. Wireless Router:  Create an instant private wireless network, also can as a router function.
