▪ Test 4 types of cables: RJ-45, RJ-11, USB and BNC. Test installed wiring or patch cables.
▪ Tests shielded (STP) or unshielded (UTP) LAN cable, test shields in USB cables.
▪ Can test from 2 remote points.
▪ Beeper provides audible annunciation of test results.
▪ Remote unit stores in Main unit
▪ Multi-function Wire Tracker, locating a short or breakage in a non-powered cable, and mapping RJ45 wire. Essential for cable installers or anyone in the telecom or LAN environments.
Description:
Low Battery Indicator.
Simple one button test.
Fast speed testing.
With a soft leather bag for carrying.
High quality warranted.
Features:
Test 4 types of cables: RJ-45, RJ-11, USB and BNC. Test installed wiring or patch cables.
Tests shielded (STP) or unshielded (UTP) LAN cable, test shields in USB cables.
Can test from 2 remote points.
Beeper provides audible annunciation of test results.
Remote unit stores in Main unit.
BNC terminator 25/50 Ohm indications.
Straight or crossover indications.
LEDs indicate connections and faults of wire and pins.
RJ-11/ are equipped with 50u gold plating. 300 feet test distance (/RJ-11/BNC).
Others:
Faults Indicated: No Connections, short circuit , Opens and Crossover
Low Battery Indicator: LED lights to indicate
Battery Power: 1 x 9 V 6F22 DC Alkaline Battery (Battery Not Included)
Material: Plastic
Package dimensions: 126 x 112 x 43mm / 4.96 x 4.41 x 1.69inch
Package Includes:
1x 4-in-1 Network Cable Tester
1x Far End Remote Jack (USB RJ11) (Attached to the main unit)
1x BNC Remote Jack
1x Instruction Manual
