● Power Input: DC44V-57V;
● Power Output: DC5V, 2.4A, 12W;
● Power Pin: 1/2(+), 3/6(-) or 4/5(+), 7/8(-);
● Data Pin: 1/2: (+), 3/6: (-);
This PoE Cable working with IEEE802.3at/af compliant PDs, expands home and office network, can be used with any PoE device. Use with a power supply to power IP security cameras, phones, wireless access points and other devices.
Description:
This PoE Cable working with IEEE802.3at/af compliant PDs, expands home and office network, can be used with any PoE device. Use with a power supply to power IP security cameras, phones, wireless access points and other devices.
Features:
● 10/100Mbps POE Splitter Cable;
● Power Input: DC44V-57V;
● Power Output: DC5V, 2.4A, 12W;
● Ports: RJ45(PoE) + RJ45(LAN) + Micro USB Interface;
● Network Speed: IEEE802.3at/af;
● Network Speed: 10/100Mbps;
● Data Pin: 1/2: (+), 3/6: (-);
● Power Pin: 1/2(+), 3/6(-) or 4/5(+), 7/8(-);
● Supports various DC Power Adapters and Solar Power Battery Packs.
Speicification:
| 10/100Mbps DC48V-to-DC5V POE Splitter Cable | ||||
| Model | CPOE-08MU | CPOE-09MU | CPOE-08TC | CPOE-09TC |
| Ports | PoE (RJ45) + LAN (RJ45) + Micro USB | PoE (RJ45) + LAN (RJ45) + Type-C | ||
| PoE Support | IEEE802.3at/af | |||
| Power Input | DC44V-57V | DC44V-57V | DC44V-57V | DC44V-57V |
| DC Output | DC5V, 2.4A, 12W | DC5V, 2.4A, 12W | DC5V, 2.4A, 12W | DC5V, 2.4A, 12W |
| DC Connector | Micro USB interface | Type-C interface | ||
| Data Speed | 10/100Mbps | |||
| Data Pin | 1/2: (+), 3/6: (-) | |||
| Power Pin | 1/2(+), 3/6(-) or 4/5(+), 7/8(-) | |||
| Extend Distance | 0~100M | |||
| Network Cable | Un-shielded or Shielded Cat5E, Cat6 or Better | |||
| Temperature | Working: -10℃~+50℃, Store: -20℃~+85℃ | |||
| Humidity | Working: 20~90%RH, Store: 10~95%RH | |||
| Material | ABS Plastic Housing | |||
