CHM-M1602

  • 6x2 HDMI Matrix Support 4Kx2K@30Hz 3D ARC
  • Support HDMI 1.4b
  • Support 3.2G data rate and TMDS clock up to 320Mhz
  • Support 3.5mm stereo audio output and optical output
  • Product description: 6x2 HDMI Matrix Support 4Kx2K@30Hz 3D ARC; 1. Support HDMI 1.4b; 2. Support ARC; 3. Support 3.2G data rate and TMDS clock up to 320Mhz; 4. 4K/30Hz: Transmit distance(AWG26): up to 10M(5M+5M) ; 6.
  • INQUIRY   EMAIL

Download for More Details

This 6X2 HDMI matrix can easily switch or distribute the input of six high-definition signals on two high-definition monitors or projectors ,which can display different image or the same image.
This product has optical fiber and stereo output interfaces. The output audio can be selected in the two output screens through the function buttons.
This product has picture-in-picture function. A large screen contains five small screens, which can be activated by remote control, It is convenient to select different display way.
This product supports high-definition 4K / 30Hz resolution,which is the perfect assistant for home entertainment and office meetings.

Features:
Support HDMI 1.4b.
Support ARC (Only for OUTA)
Support 3D video format.
Support highest resolution up to 3840x2160/30Hz.
Support 3.2G data rate and TMDS clock up to 320Mhz.
Support deep color 8/10/12 bit.
Support 3.5mm stereo audio output and SPDIF optical output.
Support six HDMI input to be switched or splitted two HDMI output.
Support 5.1 audio channel.
Support audio EDID select

Specifications:
HDMI version..................................................HDMI 1.4b
HDMI resolution............................................Up to 3840*2160/30Hz
Support video format.................................8/10/12 bit deep color
Support audio format.................................DTS-HD/Dolby-trueHD//DTS/Dolby-AC3/DSD
Max bandwidth...................................................320MHz
Max baud rate....................................................3.2Gbps
Input cable distance..........................................≤5m AWG26 HDMI standard cable
output cable distance.........................................≤5m AWG26 HDMI standard
cable Max working current.................................1000mA
Power adapter format..........................................Input: AC (50HZ,60HZ) 100V-240V;
Output.......................................................................DC5V
Operating Temperature range..........................(-15 to +55℃)
Operating Humidity range................................5 to 90% RH (No Condensation)
Dimension (LxWxH)...........................................255x70x21(mm)
Weight......................................................................625g

Package Contents:
1pcs.........HDMI matrix
1pcs.........Infrared remote control
1pcs........ 5V 2A power adapter
1pcs.........User Manual
