▪ 1-to-2 10/100Mbps PoE Extender;
▪ Interface: 3 * 10/100Mbps RJ45 port;
▪ Input Voltage: POE Power;
▪ Output Voltage: DC44V-57V ( Normal DC48V);
▪ Power supply: Support 12+ /36- power supply;
▪ PoE Extender Distance: 10-120m;
▪ PoE Standard: IEEE802.3af, IEEE802.3at;
▪ Product Size: 79*52*23mm(L*W*H);
▪ The POE extension device provides two 100Mbps power supply ports and one 100Mbps up-link power supply port. 1-2 ports support IEEE 802.3af/at standard POE power supply, and the POE power of a single port is up to 30Watt.
Description:
POE Extender is mainly used to cooperate with High PoE Midspan to formlong-distance transmission plan, transmit Ethernet data via Cat5/5e/6Network Cable and supply power for IP Camera, cascade multileveltransmission 300m.
Feature:
▪ 1-to-2 10/100Mbps PoE Extender;
▪ Interface: 3 * 10/100Mbps RJ45 port;
▪ Input Voltage: POE Power;
▪ Output Voltage: DC44V-57V ( Normal DC48V);
▪ Power supply: Support 12+ /36- power supply;
▪ PoE Extender Distance: 10-120m;
▪ PoE Standard: IEEE802.3af, IEEE802.3at;
▪ Backplane bandwidth: 1G;
▪ Network bandwidth: 10/100M;
▪ Product Size: 79*52*23mm(L*W*H);
▪ Product Weight: 57g/unit.
Specification:
| Model | C-PFT1300 |
| Interface | 3*10/100Base-TX POE port (Data/Power） |
| Transmission distance | 100BASE-TX：Cat5 or later UTP(≤100meter) |
| Network protocol | IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX; IEEE802.3x |
| Forwarding mode | Storage and forwarding (full line speed) |
| POE standard | Support IEEE802.3af/at |
| Power Supply Type | Default 1/2(+)，3/6(-) or 4/5(+)，7/8(-) |
| Maximum POE power | 30Watt |
| Power consumption | ＜2Watt |
| Input voltage and interface | POE(IEEE802.3af/at)，RJ45 port |
| Temperature | Working: -30℃～65°C |
| Product size | 79*52*23mm(L*W*H) |
| Product weight | 57g |
