CPP01-5E-24AP 24-Port Cat5e Patch Panel for 19In Rack Mount

Description:

A patch panel in a local area network (LAN) is a mounted hardware assembly that contains ports that are used to connect and manage incoming and outgoing LAN cables. A patch panel provides a way to keep large numbers of cables organized, enabling flexible connectivity into network hardware located in a data center or an access or wiring closet.

The patch panel hardware assembly contains blank ports on one side and a termination point on the other. Cables running throughout a building or campus can be terminated, labeled and then patched into network or audiovisual (AV) hardware.

Feature:

▪ 1U 24-Port Cat5e Patch Panel for 19 Inch Rack Mount;

▪ Gold-plated RJ45 8P8C contacts with numbered ports;

▪ Label spaces for hand-written or machine-printed labels;

▪ Dimension: 480*86*45mm;

▪ Material: SPCC Steel;

▪ Suitable for wires installation by KRONE punch down tools;

▪ TIA/EIA 568A and 568B wiring for easily wiring installation reference;

▪ Accessories: Include Screws & Cable Ties;

▪ The RJ45 8P8C Socket on the patch panel is available for connection with RJ11/RJ12(6P4C,6P6C) Telephone cable plug.

Speicification:
