Feature:
◆ 10x 10/100/1000Mbps auto-sensing RJ45 ports,
8x 10/100/1000Mbps PoE ports, 2x10/100/1000Mbps uplink port ;
◆ Supports port auto-flip (Auto MDI/ MDIX);
◆ Maximum power of single PoE port: 15.4W/30W;
◆ Adopts store-and-forward architecture;
◆ IEEE 802.3af/at power on up to 8 ports;
◆ With anti-theft lock;
◆ Protection: Excellent anti thunder, anti static and anti-Interference;
◆ Built in power supply, compact and quiet design,suitable for desktop or wall
Specification
Model | CPE-G4308B |
Power Adapter voltage | 48-57V DC |
POE Ethernet port | 1-8 port: 10/100/1000Mbps |
Ethernet port | 2*Uplink port: 10/100/1000Mbps |
Transmission Distance | 1-8 port: 0-100m, uplink port: 100m, via Cat5/ 5e/ 6 standard Network Cable |
Network standard | IEEE 802.3/ 802.3u, IEEE 802.3x, IEEE 802.1p, IEEE 802.3az |
Switching capacity | 20Gbps |
Packet Forwarding rate | 14Mpps |
MAC table | 4K |
POE Standard | IEEE 802.3AF/AT |
POE Power Supply type | End-span (1/2+, 36-) |
POE power consumption | af=15.4W (each port), at=30W (each port) |
Working temperature |
0℃~55℃ |
Relative humidity |
20~95% |
Storage temperature |
-20℃~70℃ |
MTBF | >30000h |
